UL10064 FEP Wire with Multiple AWG Sizes 30V Rated Voltage and 105°C Temperature Rating for Internal or External Interconnection Cable

  • UL10064 FEP Wire with Multiple AWG Sizes 30V Rated Voltage and 105°C Temperature Rating for Internal or External Interconnection Cable
  • UL10064 FEP Wire with Multiple AWG Sizes 30V Rated Voltage and 105°C Temperature Rating for Internal or External Interconnection Cable
  • UL10064 FEP Wire with Multiple AWG Sizes 30V Rated Voltage and 105°C Temperature Rating for Internal or External Interconnection Cable
  • UL10064 FEP Wire with Multiple AWG Sizes 30V Rated Voltage and 105°C Temperature Rating for Internal or External Interconnection Cable
  • UL10064 FEP Wire with Multiple AWG Sizes 30V Rated Voltage and 105°C Temperature Rating for Internal or External Interconnection Cable
  • UL10064 FEP Wire with Multiple AWG Sizes 30V Rated Voltage and 105°C Temperature Rating for Internal or External Interconnection Cable
Lugar de origen Cantón, China
Nombre de la marca MYSUN
Número de modelo UL1858
Cantidad de orden mínima 3050

Éntreme en contacto con gratis las muestras y los vales.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

skype: sales10@aixton.com

Si usted tiene alguna preocupación, proporcionamos ayuda en línea de 24 horas.

x
Datos del producto
Material conductor Cobre estampado Diámetro 16 AWG, 18 AWG, 20 AWG, 22 AWG, 24 AWG, 26 AWG
Material de aislamiento Goma Tensión nominal 30V
Tipo de conductor Sólido Forma Redondo
Temperatura 105°C Tipo Aislado
Color Todos los colores Longitud de la unidad 305/1000
Resistencia del conductor máximo 14,6 Ω/KM (16 AWG) Espesor nominal 0,300 mm (16 CAE)
Diámetro de aislamiento 2,09 mm (16 CAE) Construcción 19/0,30 (16 CAE)
Diámetro del conductor 1,49 mm (16 CAE)
Resaltar

Multiple AWG Sizes FEP Wire

,

30V Rated Voltage UL10064 Wire

,

105°C Temperature Rating Tefzel Insulated Wire
Deja un mensaje
Descripción de producto
UL10064 FEP Wire for Further Processing As Insulated Singles in Internal or External Interconnection Cable
Supplies Fortune 500 Companies Top High Temperature Wire Supplier In China.
UL10064 FEP Wire with Multiple AWG Sizes 30V Rated Voltage and 105°C Temperature Rating for Internal or External Interconnection Cable 0 UL10064 FEP Wire with Multiple AWG Sizes 30V Rated Voltage and 105°C Temperature Rating for Internal or External Interconnection Cable 0
Specification
UL10064 UL1330
Conductor Insulation Max.Cond Resistance (Ω/KM) Unit length (M)(Ft)
Size (AWG) Construction (No.mm) Diameter (mm) Nominal thickness (mm) Diameter (mm)
32 7/0.08 0.24 0.200 0.64 563 610/2000
30 7/0.10 0.30 0.200 0.70 381 610/2000
28 7/0.127 0.38 0.250 0.88 239 610/2000
26 7/0.16 0.48 0.300 1.08 150 610/2000
24 7/0.20 0.61 0.300 1.21 94.2 610/2000
22 19/0.15 0.77 0.300 1.37 59.4 305/1000
20 19/0.19 0.92 0.300 1.52 36.7 305/1000
18 19/0.235 1.19 0.300 1.79 23.2 305/1000
16 19/0.30 1.49 0.300 2.09 14.6 305/1000
14 19/0.37 1.87 0.350 2.57 8.78 305/1000
