UL1901 FEP Wire 600V 200C High Temperature Wire for Industrial Robots and Drones
Éntreme en contacto con gratis las muestras y los vales.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
Si usted tiene alguna preocupación, proporcionamos ayuda en línea de 24 horas.
xDatos del producto
| Material conductor | Cobre estampado | Diámetro | 10 AWG, 12 AWG, 14 AWG, 16 AWG, 18 AWG, 20 AWG, 22 AWG, 24 AWG, 6 AWG, 8 AWG, 4 AWG, 2 AWG, 1 AWG, 2 |
|---|---|---|---|
| Material de aislamiento | Goma | Tensión nominal | 600 V |
| Tipo de conductor | Sólido | Forma | Redondo |
| Calificación de temperatura | 200℃ | Tipo | Aislado |
| Longitud de la unidad | 305/1000 | Espesor de aislamiento | 0,350 mm, 0,500 mm, 0,760 mm |
| Resistencia del conductor máximo | 381 Ω/KM, 239 Ω/KM, 150 Ω/KM, 94,2 Ω/KM, 59,4 Ω/KM, 36,7 Ω/KM, 23,2 Ω/KM, 14,6 Ω/KM, 8,96 Ω/KM, 5,64 | Construcción de conductores | 7/0,10, 7/0,12, 7/0,16, 7/0,20, 19/0,15, 19/0,19, 19/0,235, 19/0,30, 19/0,37, 19/0,47, 19/0,43, 37/0 |
| Diámetro nominal | 0,30 mm, 0,36 mm, 0,48 mm, 0,60 mm, 0,75 mm, 0,93 mm, 1,17 mm, 1,50 mm, 1,85 mm, 2,35 mm, 3,00 mm, 3 | Diámetro de aislamiento | 1,00 mm, 1,08 mm, 1,18 mm, 1,30 mm, 1,45 mm, 1,63 mm, 1,87 mm, 2,20 mm, 2,55 mm, 3,05 mm, 3,70 mm, 4 |
| Resaltar | UL1901 FEP Wire,600V High Temperature Wire,200C Robot Cable |
||
Descripción de producto
UL1901 FEP Wire AWG 600V 200°C High Temperature Wire for Robot Cable
Supplies Fortune 500 Companies - Top PFA Wire Supplier In China.
Specification
| UL1901 | Conductor | Insulation | Max. Cond Resistance (Ω/KM) | Unit length (M)(Ft) | ||
|---|---|---|---|---|---|---|
| Size (AWG) | Construction (No.mm) | Diameter (mm) | Nominal thickness (mm) | Diameter (mm) | ||
| 30 | 7/0.10 | 0.30 | 0.350 | 1.00 | 381 | 610/2000 |
| 28 | 7/0.12 | 0.36 | 0.350 | 1.08 | 239 | 610/2000 |
| 26 | 7/0.16 | 0.48 | 0.350 | 1.18 | 150 | 610/2000 |
| 24 | 7/0.20 | 0.60 | 0.350 | 1.30 | 94.2 | 610/2000 |
| 22 | 19/0.15 | 0.75 | 0.350 | 1.45 | 59.4 | 305/1000 |
| 20 | 19/0.19 | 0.93 | 0.350 | 1.63 | 36.7 | 305/1000 |
| 18 | 19/0.235 | 1.17 | 0.350 | 1.87 | 23.2 | 305/1000 |
| 16 | 19/0.30 | 1.50 | 0.350 | 2.20 | 14.6 | 305/1000 |
| 14 | 19/0.37 | 1.85 | 0.350 | 2.55 | 8.96 | 305/1000 |
| 12 | 19/0.47 | 2.35 | 0.350 | 3.05 | 5.64 | 305/1000 |
| 10 | 19/0.43 | 3.00 | 0.350 | 3.70 | 3.55 | 305/1000 |
| 8 | 37/0.54 | 3.78 | 0.500 | 4.78 | 2.23 | Customize |
| 7 | 37/0.60 | 4.20 | 0.500 | 5.20 | 1.77 | Customize |
| 6 | 37/0.68 | 4.76 | 0.500 | 5.76 | 1.41 | Customize |
| 5 | 37/0.76 | 5.32 | 0.500 | 6.32 | 1.12 | Customize |
| 4 | 37/0.86 | 6.02 | 0.500 | 7.02 | 0.89 | Customize |
| 3 | 7/2.21 | 6.63 | 0.500 | 7.63 | 0.71 | Customize |
| 2 | 7/2.48 | 7.44 | 0.500 | 8.44 | 0.56 | Customize |
| 1 | 7/2.78 | 8.34 | 0.760 | 9.86 | 0.4268 | Customize |
| 0 | 7/3.20 | 9.60 | 0.760 | 11.12 | 0.3367 | Customize |
| 2/0 | 7/3.57 | 10.71 | 0.760 | 12.23 | 0.267 | Customize |
| 3/0 | 7/3.94 | 11.82 | 0.760 | 13.34 | 0.2119 | Customize |
| 4/0 | 7/4.42 | 13.26 | 0.760 | 14.78 | 0.168 | Customize |
Company Profile
Our Products
Application
Our Overseas Clients
Exhibition
Certifications
FAQ
- Who Are We? We are a professional manufacturer of high-temperature wires and cables with 26 years of electric wire experience. Our headquarter is located in Shenzhen, Guangdong, China, and our two production bases are located in Dongguan, Guangdong, China and Jingzhou, Hubei, China.
- What Can We Provide? We can provide high-temperature wires and cables, silicone tubing - including silicone rubber wire, XLPE, FEP/PFA/ETFE/PTFE wire, new energy cable, wiring harnesses.
- Why Choose Us? A. Free Sample. B. Competitive Price. C. High Quality Standard. D. Customized Service.
- What Certifications Do We Have? We have UL, cUL, VDE, Reach, CE, ROHS, CCC, CQC Certification.
- What Services Can We Provide? Accepted Delivery Terms: FOB, CIF, EXW, FAS, CIP, FCA, DDP, DDU. Accepted Payment Currency: USD, EUR, CNY. Accepted Payment Type: T/T, L/C, PayPal, Western Union, Cash.
