UL3512 12AWG Super Soft Silicone Insulated Wire with 660/0.08 Tinned Copper for High Temperature Applications

  • UL3512 12AWG Super Soft Silicone Insulated Wire with 660/0.08 Tinned Copper for High Temperature Applications
  • UL3512 12AWG Super Soft Silicone Insulated Wire with 660/0.08 Tinned Copper for High Temperature Applications
  • UL3512 12AWG Super Soft Silicone Insulated Wire with 660/0.08 Tinned Copper for High Temperature Applications
  • UL3512 12AWG Super Soft Silicone Insulated Wire with 660/0.08 Tinned Copper for High Temperature Applications
  • UL3512 12AWG Super Soft Silicone Insulated Wire with 660/0.08 Tinned Copper for High Temperature Applications
  • UL3512 12AWG Super Soft Silicone Insulated Wire with 660/0.08 Tinned Copper for High Temperature Applications
Lugar de origen Guangdong, China
Nombre de la marca MYSUN
Certificación UL Certification
Número de modelo E239689
Cantidad de orden mínima 2000
Precio $0.30-0.60

Éntreme en contacto con gratis las muestras y los vales.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

skype: sales10@aixton.com

Si usted tiene alguna preocupación, proporcionamos ayuda en línea de 24 horas.

x
Datos del producto
Material conductor Alambre de cobre estampado Diámetro 12 AWG
Material de aislamiento Goma de silicona Voltaje nominal 600V
Tipo de conductor Cobre estampado Forma Redondo
Temperatura 200c Tipo Aislado
Conductor Núcleo de cobre Aislamiento Cable de aislamiento de caucho de silicona
Material Cobre Chaqueta Goma de silicona
Tamaño del conductor 660/0.08 Espesor nominal 0.78 mm
Tolerancia del diámetro 4.30 ± 0.1 mm
Resaltar

660/0.08 Silicone Insulated Wire

,

Super Soft Silicone Rubber Wire

,

12AWG UL3512 Wire
Deja un mensaje
Descripción de producto
UL3512 12AWG Super Soft Silicone Wire 660/0.08 High Temperature Lithium Battery Cable
Premium Silicone Rubber Wire Supplier
Supplies Fortune 500 companies. Leading silicone rubber wire supplier in China.
UL3512 12AWG Super Soft Silicone Insulated Wire with 660/0.08 Tinned Copper for High Temperature Applications 0 UL3512 12AWG Super Soft Silicone Insulated Wire with 660/0.08 Tinned Copper for High Temperature Applications 1
Product Specifications
Conductor Size (AWG) Construction (No./mm) Diameter (mm) Nominal Thickness (mm) Diameter (mm)
2625/0.080.480.782.10±0.1
2441/0.080.600.782.20±0.1
2265/0.080.780.782.50±0.1
20104/0.080.950.782.55±0.1
18164/0.081.170.782.80±0.1
16261/0.081.470.783.10±0.1
14415/0.082.100.783.70±0.1
12660/0.082.700.784.30±0.1
101050/0.083.40±0.301.155.50±0.2
91320/0.083.80±0.31.156.10±0.3
81650/0.084.00±0.301.156.30±0.3
72100/0.084.80±0.31.527.90±0.3
62648/0.085.30±0.301.528.30±0.4
53338/0.086.10±0.51.529.20±0.4
44210/0.086.80±0.51.529.90±0.4
35309/0.087.80±0.51.5210.9±0.5
26692/0.088.70±0.51.5211.8±0.5
18842/0.0810.0±0.62.0314.0±0.6
1/010647/0.0811.0±0.702.0315.0±0.6
2/013422/0.0812.3±0.82.0316.3±0.7
3/016921/0.0814.50±0.702.0318.50±0.60
4/021338/0.0815.2±0.82.0320.5±1.0
Contact Us to Get the Most Cost-effective Quote
UL3512 12AWG Super Soft Silicone Insulated Wire with 660/0.08 Tinned Copper for High Temperature Applications 2 UL3512 12AWG Super Soft Silicone Insulated Wire with 660/0.08 Tinned Copper for High Temperature Applications 3 UL3512 12AWG Super Soft Silicone Insulated Wire with 660/0.08 Tinned Copper for High Temperature Applications 4 UL3512 12AWG Super Soft Silicone Insulated Wire with 660/0.08 Tinned Copper for High Temperature Applications 5
Our Products
UL3512 12AWG Super Soft Silicone Insulated Wire with 660/0.08 Tinned Copper for High Temperature Applications 6
Applications
UL3512 12AWG Super Soft Silicone Insulated Wire with 660/0.08 Tinned Copper for High Temperature Applications 7
Company Profile
UL3512 12AWG Super Soft Silicone Insulated Wire with 660/0.08 Tinned Copper for High Temperature Applications 8 UL3512 12AWG Super Soft Silicone Insulated Wire with 660/0.08 Tinned Copper for High Temperature Applications 9
Our Overseas Clients
UL3512 12AWG Super Soft Silicone Insulated Wire with 660/0.08 Tinned Copper for High Temperature Applications 10
Exhibition
UL3512 12AWG Super Soft Silicone Insulated Wire with 660/0.08 Tinned Copper for High Temperature Applications 11
Certifications
UL3512 12AWG Super Soft Silicone Insulated Wire with 660/0.08 Tinned Copper for High Temperature Applications 12
Frequently Asked Questions
  • Who Are We? We are a professional manufacturer of high-temperature wires and cables with 26 years of electric wire experience. Our headquarters is located in Shenzhen, Guangdong, China, with production bases in Dongguan and Jingzhou.
  • What Can We Provide? High-temperature wires and cables, silicone tubing including silicone rubber wire, XLPE, FEP/PFA/ETFE/PTFE wire, new energy cable, and wiring harnesses.
  • Why Choose Us? Free samples, competitive pricing, high quality standards, and customized services.
  • What Certifications Do We Have? UL, cUL, VDE, Reach, CE, ROHS, CCC, CQC certification.
  • What Services Can We Provide? Accepted delivery terms: FOB, CIF, EXW, FAS, CIP, FCA, DDP, DDU. Accepted payment currency: USD, EUR, CNY. Accepted payment type: T/T, L/C, PayPal, Western Union, Cash.
